Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-76
Table 6-23. A18 Filter/PA Supply PCA (cont)
Reference
Designator
Description
Fluke
Stock
No
Tot Qty Notes
Q201,Q202 * TRANSISTOR,SI,N-MOS,40W,500V,T0-220 782540 2 1
Q203,Q206 * PNP,2N6520 R05A,TRANSISTOR,SI,PNP,350V,625MW,TO-92 602961 2
Q204,Q209, Q210,
Q212
*
*
TRANSISTOR,SI,P-MOS,500V,TO-92 782508
782508
4
Q205,Q207, Q208,
Q213
*
*
TRANSISTOR,SI,N-DMOS,500V,TO-92 782490
782490
4
Q211,Q214 * TRANSISTOR,SI,NPN,350V,0.625MW,TO-92 853994 2
Q215,Q216 * TRANSISTOR,SI,P-MOS,POWER,500V 782482 2 2
Q217 * TRANSISTOR,SI,100V,10W,TO-202 943803 1
Q218 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 1
Q219 * TRANSISTOR,SI,PNP,40V,0.35W,TO-92 698233 1
R1 RESISTOR A73R,RES,CERM,560,+-5%,2W,100PPM 643764 1
R2-5 RESISTOR A52R,RES,CF,20K,+-5%,0.5W 641099 4
R201,R244 RES,CF,8.2,+-5%,0.25W 442269 2
R202,R243 RES,CF,5.1,+-5%,0.25W 441287 2
R203,R241, R256,
R257
RES,CF,9.1K,+-5%,0.25W 706663
706663
4
R204,R253 RES,CF,1.5,+-5%,0.25W 732800 2
R205,R216, R229,
R240
RESISTOR A52R,RES,CF,560K,+-5%,0.5W 640364
640364
4
R206,R239 RES,CF,1M,+-5%,0.25W 649970 2
R207,R209, R237,
R238
RESISTOR A52R,RES,CF,470K,+-5%,0.5W 641107
641107
4
R208,R210, R235,
R236
RESISTOR A73R,RES,CERM,220K,+-5%,3W,100PPM 642428
642428
4
R211 RES,CF,47,+-5%,0.25W 822189 1
R212,R220, R222,
R231, R242
RES,CF,33K,+-5%,0.25W 733667
733667
733667
5
R213,R217,R218,
R230, R232,R245,
R249
RES,CF,10K,+-5%,0.25W 697102
697102
697102
7
R214,R233 RES,CF,200K,+-5%,0.25W 681841 2
R215,R234 RESISTOR A52R,RES,CF,330,+-5%,0.5W 686789 2
R221,R250 RES,CF,82K,+-5%,0.25W 655027 2
R225 RES,CF,100K,+-5%,0.25W 348920 1
R226,R248 RES,MF,3.16K,+-1%,0.125W,100PPM 235291 2
R228,R247 RES,CF,100K,+-5%,0.25W 658963 2
R246,R251 RES,CF,4.7K,+-5%,0.25W 721571 2
R252 RES,CF,300K,+-5%,0.25W 732818 1
R254,R255 RESISTOR A52R,RES,CF,27,+-5%,0.5W 260984 2
RT1,RT2 THERMISTOR,DISC,POSITIVE,50,+-30% 816140 2
TP201 SOCKET,SINGLE,PWB,FOR 0.080 PIN 170480 1
TP204 SOCKET,SINGLE,PWB,FOR 0.080 PIN 149120 1
TP1-22,TP203,
TP205-212
JUMPER,WIRE,NONINSUL,0.200CTR 816090
816090
31
U1 * IC, VOLT REG,FIXED,-5 VOLTS,0.5 AMPS 816322 1
U2 * IC,VOLT REG,FIXED,+5 VOLTS,0.1 AMPS 816355 1
U3 * IC,VOLT REG,FIXED,-18 VOLTS,1.5 AMPS 845474 1
U201 * IC,COMPARATOR,QUAD,14 PIN DIP 387233 1
VR20,VR21 * ZENER,UNCOMP,82.0V,5%,1.5MA,0.5W 844977 2
VR202,VR213,
VR233,VR242
*
*
ZENER 1N5240B
A52R,ZENER,UNCOMP,10.0V,5%,20.0MA,0.5W
473744
473744
10
VR206,VR207,
VR218,VR228,
VR237,VR238
*
*
*
ZENER,UNCOMP,10.0V,5%,20.0MA,0.5W 473744
473744
473744
1. Q201, Q202- Assembly 665486 use part numbers 816546, 534453, 782540, 844824, 256156, 110635
2. Q215,Q216- Assembly 665463 use part numbers 816546, 534453, 782482, 844824, 256156, 110635

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
