Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-77
Table 6-23. A18 Filter/PA Supply PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
VR211,VR217,
VR227,VR231
*
*
ZENER,UNCOMP,140.0V,5%,1.8MA,1.0W 340703
340703
4
VR212,VR216,
VR226,VR232
*
*
ZENER,UNCOMP,180V,2%,0.68MA,0.4W 816348
816348
4
VR214,VR230,
VR246,VR247
*
*
ZENER,UNCOMP,56V,5%,2.2MA,0.4W 832568
832568
4
VR215,VR219,
VR225,VR229
*
*
ZENER,UNCOMP,200.0V,5%,5.0MA,5.0W 386839
386839
4
VR245 * ZENER,UNCOMP,3.3V,5%,20.0MA,0.4W 820423 1
Z1-3 RES,CERM,SIP,10 PIN,5 RES,10K,+-2% 529990 3
Z201 RES,CERM,SIP,6 PIN,5 RES,100K,+-2% 412726 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
