Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-79
Table 6-24. A19 Digital Power Supply PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1 CAP,AL,470UF,+-20%,160V 816835 1
C2 CAP,AL,10UF,+-20%,160V,SOLV PROOF 817064 1
C3 CAP,AL,330UF,+-20%,100V,SOLV PROOF 816785 1
C4,C9 CAP,AL,10UF,+-20%,63V,SOLV PROOF 816843 2
C5,C11 CAP,CER,0.10UF,+-20%,50V,X7R 853650 2
C6 CAP,AL,10000UF,+-20%,25V 816819 1
C7 CAP,AL,6800UF,+-20%.25V 782466 1
C8 CAP,AL,2.2UF,+-20%,50V,SOLV PROOF 816868 1
C10 CAP,AL,22UF,+-20%,35V 817056 1
C12,C13 CAP,AL,22000UF,+-20%,16V 822379 2
C14,C16,C19-23 CAP,CER,0.22UF,+-20%,50V,X7R 853648 7
C15 CAP,AL,100UF,+-20%,16V,SOLV PROOF 816850 1
C17 CAP,POLYPR,0.047UF,+-10%,630V 500827 1
C18 CAP,POLYPR,0.047UF,+-10%,160V 446773 1
C24,C25 CAP,CER,0.022UF,+80-20%,500V,Z5U 740340 2
CR1-4,CR9-12 DIODE,SI,200 PIV,1.0 AMP 586644 8
CR8,CR16, CR21-
24,CR29-34
DIODE,SI,100 PIV,1 AMP 707075 12
CR13 * DIODE,SI,N-JFET,CURRENT REG,IF 852137 1
CR17-20 DIODE,SI,50 PIV,1.0 AMP 379412 4
CR25-28 DIODE,SI,150 PIV,5.0 AMP 523720 4
CR35 * DIODE,GER,BV=66V,IO=50MA 180505 1
F1 FUSE,8X8.5MM,0.315A,250V,SLOW,RADIAL 832337 1
F2 FUSE,8X8.5MM,0.125A,250V,SLOW,RADIAL 832261 1
F3,F4 FUSE,8X8.5MM,2A,250V,SLOW,RADIAL 806331 2
F5 FUSE,8X8.5MM,3.15A,250V,SLOW,RADIAL 832253 1
H2 SCREW,PH,P,LOCK,SS,4-40,.375 256164 1
H3,H4 HEAT DIS,CLIP,1.00,1.18,.50,TO-220 643353 2
H5 HEAT DIS,VERT FINS,TO-3 342675 1
H6,H7 RIVET,S-TUB,OVAL,AL,.087,.343 838458 2
H11 SCREW,PH,P,LOCK,SS,4-40,.437 403782 1
L1-6 CHOKE,6TURN 320911 6
L7 INDUCTOR, 33UH 813485 1
L8 TRANSFORMER, PULSE 660589 1
M1,M2 FOOT,RUBBER,ADHES,GRY,.44 DIA,.20 THK 1601870 2
MP8,MP27 NUT,HEX,STL,4-40 110635 2
MP9,MP10 NUT,EXT LOCK,STL,6-32,.344OD 152819 2
MP11,MP12 GROMMET,SLOT,RUBBER,.438,.062 853291 2
MP13,MP14 EJECTOR,PWB,NYLON 494724 2
MP15,MP26 HEAT DIS,VERT,1.00X1.375X0.50,TO-220 831099 2
MP16 HEAT,DIS,ACC,NYL,TO-3 851907 1
MP21 INSUL PT,POWER,SI,.750,.500 534453 1
MP24 INSUL PT,TO-3,SI,1.650,1.140 473165 1
MP25 INSUL PT,TRANSISTOR MOUNT,DAP,TO-5 152207 1
MP28,MP29 SCREW,PH,P,LOCK,STL,6-32,.250 152140 2
MP30,MP31 SPACER,SWAGE,.250 RND,BR,6-32,.125 435578 2
P41 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 1
Q1 * TRANSISTOR,SI,BV=200V,80W,TO-3 261347 1 1
Q2,Q6 * TRANSISTOR,SI,NPN,HI-VOLTAGE 370684 2
Q3,Q7-10 * TRANSISTOR,SI,300V,10W,TO-202 107646 5
Q4 * TRANSISTOR,SI,VCB=200V,1W,TO-3 276899 1
Q5 * TRANSISTOR,SI,BV=60V,65W,TO-220 386128 1
R1 RES,CF,5.1,+-5%,0.25W 441287 1
R2 RES,CF,2K,+-5%,0.25W 441469 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
