Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-80
Table 6-24. A19 Digital Power Supply PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
R3,R12 RES,CF,100K,+-5%,0.25W 348920 2
R4 RES,CC,4.7K,+-5%,0.25W 348821 1
R5 RES,CF,12,+-5%,0.25W 442178 1
R6 RES,CC,10K,+-10%,2W 641123 1
R7 RES,CC,2,+-5%,0.5W 641057 1
R8 RES,CF,120K,+-5%,0.25W 441386 1
R9,R11 RES,CF,33K,+-5%,0.25W 348888 2
R10 RES,CF,51K,+-5%,0.25W 376434 1
R13 RES,CC,10K,+-5%,0.25W 148106 1
TP1-5,TP8,TP10,
TP12,TP13
JUMPER,WIRE,NONINSUL,0.200CTR 816090
816090
9
U1 * IC,VOLT REG,FIXED,+12 VOLTS,1.5 AMPS 413195 1 2
U2 * IC,VOLT REG,FIXED,-12 VOLTS,1.5 AMPS 381665 1
U3 * IC,VOLT REG,FIXED,5 VOLTS,2 AMPS 816918 1 3
VR5 * ZENER,UNCOMP,6.2V,5%,20.0MA,0.4W 325811 1
VR6 * ZENER,UNCOMP,36.0V,5%,3.4MA,0.4W 186163 1
VR7 * ZENER,UNCOMP,39.0V,5%,3.2MA,0.4W 831248 1
VR14,VR15 * ZENER,UNCOMP,18.0V,5%,7.0MA,0,4W 327973 2
1. Q1 is a heatsink assembly, part number 665422, consisting of part numbers 261347, 851907, 342672, 473165, and 152819
2. U1 is a heatsink, part number 665471, consisting of part numbers 413195, 831099, 534453, 256164, 110635
3. U3 is a heatsink, part number 665478, consisting of part numbers 816918, 831099, 403782, 110635

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
