1-6 Section 1: Introducing the Model 9100
Final Width = 215mm
1.3 Model 9100 Options
and Associated Products
The available options for the 9100 are as follows:
Option 10 Blank 256kByte, Flash memory.
Option 30 Blank 256kByte, Static RAM (SRAM), battery backed.
Option 60 Soft Carry Case.
Option 70 NAMAS Calibration Certificate traceable to National Standards.
Option 90 Rack Mounting Kit.
Option 100 High Stability Crystal Reference.
Option 200 10- and 50-Turn Current Coils.
Option 250 250MHz Oscilloscope Calibrator Module.
or
Option 600 600MHz Oscilloscope Calibrator Module.
Line Voltage: The 9100 is configured for use at the correct voltage at the shipment
point.
In addition, the following associated products are available:
PLC-XXX Procedure Library Cards (Sub-section 1.4).
Model 9105 Comprehensive Lead Set.
Portocal II Windows Automated Calibration Software and ISO 9000 Database
Manager includes full networking capabilities and procedure library,
CD-ROM, user's handbook and R & R Report Writer™ package.
9010 Windows Procedure Generator and Inventory Management Software
offers automated calibration using the 9000, 9100 and 9500 calibrators
via the IEEE-488 interface, and the capability to program procedure
cards for the 9000, 9100 and 9500 calibrators. 9010 also includes full
networking capabilities and procedure library, CD-ROM, user's
handbook and R & R Report Writer™ package.
