Section 4: Using the Model 9100: Frequency Function 4.9-3
Final Width = 215mm
4.9.3 Screen Keys
4.9.3.1 Bottom Screen Keys
Hz Selects
Frequency when Mark/Period or Duty Cycle is active.
Selects Mark/Period when Frequency or Duty Cycle is active.
% DUTY
Selects Duty Cycle when Frequency or Mark/Period is active.
4.9.3.2 Right Side Screen Keys
A. Digit Edit Facility Keys operate on the value marked by the cursor.
X 10 Multiplies the marked value by ten.
÷ 10 Divides the marked value by ten.
± Reverses the polarity of the marked value. The ± key is only available
when the cursor is marking either the High or Low Level value.
B. Direct Edit Facility Right side keys operate on the value in the edit box, and
acting in place of the ↵ key, exit from Direct Edit back to
Digit Edit; then set the value as evaluated in the box.
i. Output Frequency
Hz Evaluates the number in the box in Hertz.
kHz Evaluates the number in the box in Kilohertz.
MHz Evaluates the number in the box in Megahertz.
All Frequency values are set into the highest resolution available to their magnitude.
ii. Selected High or Low Level Value
V Evaluates the number in the box in Volts.
The selected High Level value or Low Level value is set into a resolution of four
significant digits with two decimal places.
