4.19 DC Power Function — Operation
4.19.1
This sub-section is a guide to the use of the 9100 for generating a required DC Power
output. The following topics are covered:
4.19.1.1 Default Settings and Configurations
4.19.2 Selection of DC Power Function
4.19.2.1
W Key
4.19.3 DC Power Screen Keys
4.19.3.1 Bottom Screen Keys
4.19.3.2 Right Side Screen Keys
4.19.4 Value Editing
4.19.4.1 Amplitude Editing
4.19.5 Crossing Thresholds
4.19.5.1 DC Power Resolution Thresholds
4.19.5.2 Hardware Configurations
4.19.5.3 Low and High Voltage States
4.19.5.4 Reconfiguration of High Voltage State Thresholds
4.19.6 DC Power Routines for Calibrating UUTs
4.19.6.1 Interconnections
4.19.6.2 Using the 9100 as a Fixed Source
4.19.6.3 Using the 9100 as an Adjustable Source
In this sub-section, we deal with the full range of DC Power facilities. For those who
require more detailed instructions for manipulating the front panel controls, the DC
Voltage function is used as an example for the general familiarization tutorials in
Section 3.
