Section 4: Using the Model 9100: AC Power Function - Operation 4.20-1
Final Width = 215mm
4.20 AC Power Function — Operation
4.20.1
This sub-section is a guide to the use of the 9100 for generating a required AC Power
output. The following topics are covered:
4.20.1.1 Default Settings and Configurations
4.20.2 Selection of AC Power Function
4.20.2.1
W Key
4.20.3 Screen Keys
4.20.3.1 Bottom Screen Keys
4.20.3.2 Right Side Screen Keys
4.20.3.3 Selecting Other Waveshapes
4.20.3.4 Phase-Locking Facilities
4.20.3.5 Conditions for Operation
4.20.4 Value Editing
4.20.4.1 Amplitude Editing
4.20.4.2 Frequency and Phase Editing
4.20.4.3 ‘Out of Range’
4.20.4.4 Power Factor (PF)
4.20.5 Crossing Thresholds
4.20.5.1 AC Power Resolution Thresholds
4.20.5.2 Frequency Resolution Thresholds
4.20.5.3 Hardware Configurations
4.20.5.4 Low and High Voltage States
4.20.5.5 Reconfiguration of High Voltage State Thresholds
4.20.6 Volt-Hertz Limits.
4.20.6.1 Volt-Hertz Profile
4.20.7 AC Power Routines for Calibrating UUTs
4.20.7.1 Interconnections
4.20.7.2 Using the 9100 as a Fixed Source
4.20.7.3 Using the 9100 as an Adjustable Source
In this sub-section, we deal with the full range of AC Power facilities. For those who require
more detailed instructions for manipulating the front panel controls, the DC Voltage function
was used as an example for the general familiarization tutorials in
Section 3.
