4.21 AC Harmonics Function — Operation
4.21.1
This sub-section is a guide to the use of the 9100 for generating a required AC Harmonics
output. The following topics are covered:
4.21.1.1 Default Settings and Configurations
4.21.2 Selection of AC Harmonics Function
4.21.2.1
W Key
4.21.3 Screen Keys
4.21.3.1 Bottom Screen Keys
4.21.3.2 Right Side Screen Keys
4.21.3.3 Phase-Locking Facilities
4.21.3.4 Conditions for Operation
4.21.4 Value Editing
4.21.4.1 Amplitude Editing
4.21.4.2 Frequency and Phase Editing
4.21.4.3 ‘Out of Range’
4.21.5 Crossing Thresholds.
4.21.5.1 AC Harmonics Resolution Thresholds
4.21.5.2 Frequency, Harmonic and Resolution Thresholds
4.21.5.3 Hardware Configurations
4.21.5.4 Low and High Voltage States
4.21.5.5 Reconfiguration of High Voltage State Thresholds
4.21.6 Volt-Hertz Limits
4.21.6.1 Volt-Hertz Profile
4.21.7 AC Harmonics Routines for Calibrating UUTs
4.21.7.1 Interconnections
4.21.7.2 Using the 9100 as a Fixed Source
4.21.7.3 Using the 9100 as an Adjustable Source
In this sub-section, we deal with the full range of AC Harmonics facilities. For those who
require more detailed instructions for manipulating the front panel controls, the DC
Voltage function was used as an example for the general familiarization tutorials in
Section 3.
