Section 2: Installing the Model 9100 2-3
Final Width = 215mm
2.4 Storage
The instrument should be stored under cover. The shipping container provides the most
suitable receptacle for storage, as it provides the necessary shock isolation for normal
handling operations.
Place the instrument with an active desiccant sachet inside a sealed bag. Fit the bag into
the cushioning material inside the inner carton, place this within the corner cushioning
blocks inside the outer shipping container, and locate the whole package within the
specified storage environment.
2.5 Preparation for Shipment
The instrument should be transported under cover. The original (double) shipping
container should be used to provide shock isolation for normal handling operations. Any
other container should be double-cushioned, providing similar shock isolation to the
following approximate internal packing dimensions:
Length Width Depth
Outer Box 785mm 675mm 440mm
Inner Box 675mm 565mm 315mm
Cushioned to 550mm 430mm 145mm
Place the instrument with an active desiccant sachet inside a sealed bag. Fit the bag into
the cushioning material inside the inner carton, place this within the corner cushioning
blocks inside the outer shipping container, and secure the whole package.
2.6 Calibration Enable Switch
CAUTION
This two-position, 'CAL' switch on the rear panel protects the instrument calibration
memory. The instrument was initially calibrated at the factory, so under no circumstances
should the switch be operated, until immediate recalibration is intended.
For Recalibration:
If Calibration Mode is entered while the switch is in the 'DISABLE' position, the
following warning message is placed on the screen:
Calibration switch not enabled!
