Section 5: Using the Model 9100 — Procedure Mode: Safety and General Notes 5.2-1
Final Width = 215mm
5.2 Procedure Mode —
Safety and General Notes
5.2.1 Introduction
Sub-section 5.2 introduces notes to Procedure mode. The following topics are covered:
5.2.2 Safety Features.
5.2.2.1 Output 'OFF' button.
5.2.3 Serial Mouse.
5.2.3.1 General Use of a Mouse.
5.2.3.2 Output Slewing.
5.2.4 Printing Setup.
5.2.4.1 Printer Type.
5.2.4.2 Certificate Formatting and Data Presentation.
5.2.4.3 Enable Printing.
5.2.5 Saving Results on Memory Cards.
5.2.5.1 Results Card Enabling and Insertion.
5.2.5.2 Stage-by-Stage Results Saving.
5.2.5.3 Results Memory Space.
5.2.5.4 Static RAM Card — Battery Condition.
5.2.5.5 Static RAM Card — Re-chargeable Battery.
5.2.2 Safety Features
The Model 9100 incorporates safety mechanisms in all its internal programming. For
example: a user must make an extra confirming key-press in order to raise a voltage at the
terminals above a pre-determined value.
High Voltage Warning — Take Care
After pressing OK or REPEAT PREV. keys:
If the procedure writer has not conformed strictly to the procedure-writing guidelines,
LETHAL VOLTAGES MAY APPEAR WITHOUT WARNING AT ANY POINT IN
THE PROCEDURE. ANY WARNING BEEPS SHOULD BE TAKEN VERY
SERIOUSLY!
Emergency Action — Use of OUTPUT OFF Button
In emergency, the most effective way of turning output off (other than pulling the line-
power plug) is to press the OUTPUT OFF button on the right of the front panel. This may
sound obvious, but a special feature of the OFF button operation is that as well as sending
the appropriate message to the operating system, it also has a hardware link which
bypasses the software. Even if the program has locked up, this button is effective in
cutting off the output.
