Fluke 9100 - Procedure Mode - Adjustment Only Procedure

Section 5: Using the Model 9100: Procedure Mode 5.4-1
Final Width = 215mm
5.4 Procedure Mode —
Adjustment Only Procedure
5.4.1 Introduction
Sub-section 5.4 extends the Procedure mode access guide of sub-section 5.3, to describe
elements in the use of 'Adjustment Only' Procedure. The following topics are covered:
5.4.2 'Adjustment Only' Procedure Selection.
5.4.2.1 Procedure Menu Screen for the Subject UUT Model.
5.4.2.2 Selection of 'Adjustment Only'.
5.4.3 General Sequence.
5.4.3.1 'OPERATOR PROMPT'.
5.4.3.2 'UUT ADJUST'.
5.4.3.3 High Voltage Warning.
5.4.3.4 OK / FAIL Screen Keys.
5.4.3.5 'REPEAT PREV.' Key.
5.4.3.6 'ABORT' Key and End of Procedure.
5.4.4 Verification of Results.
