Fluke 9100 - Section 4 Using the Model 9100 - Manual Mode

Section 4: Using the Model 9100: About Section 4 4.1-1
Final Width = 215mm
4.1 About Section 4
Section 4 Using the Model 9100 — Manual Mode
Section 3 should have given you practice at manipulating the front-panel controls. In
Section 4 we shall guide you, in a general way, through the phases of operating the 9100
from the front panel, to calibrate a manually-operated measuring instrument. For a guide
to using memory cards in Procedure Mode, please turn to Section 5.
Section 4 is divided into 'Functions' (DC Voltage, AC Voltage etc.) in the following sub-
sections:
4.2 Interconnections
4.3 DC Voltage
4.4 AC Voltage
4.5 DC Current
4.6 AC Current
4.7 Resistance
4.8 Conductance
4.9 Frequency
4.10 Mark/Period
4.11 % Duty
4.12 Auxiliary Functions
4.13 Capacitance
4.14 Temperature — Thermocouple
4.15 Temperature — RTD
4.16 Logic Pulses
4.17 Logic Levels
