4.19-12 Section 4: Using the Model 9100: DC Power Function - Operation
Final Width = 215mm
Sequence of Operations
Refer to the table of UUT calibration points in the UUT Manufacturers Calibration Guide.
Follow the correct sequence of calibration stages as directed by the guide, and carry out
the following operations (1) to (5) at each stage.
1. 9100 Use the front panel controls to set the 9100 Output to the UUT cal
point frequency and voltage, entering High Voltage State if the cal
point has been assigned to that State. The default High Voltage
State boundaries are discussed in Sections 4.19.5.3 and 4.19.5.4.
2. UUT Select the correct range for the cal point.
3. 9100 a. Set Output ON.
b. Slew the DC Power Output reading until the UUT reading is
equal to the calibration point value.
4. UUT Record the 9100 screen output value as detailed in the UUT
Manufacturer’s Calibration Guide.
5. 9100 Set Output OFF.
