Section 4: Using the Model 9100: DC Power Function - Operation 4.19-11
Final Width = 215mm
Sequence of Operations
Refer to the table of UUT calibration points in the UUT Manufacturers Calibration Guide.
Follow the correct sequence of calibration stages as directed by the guide, and carry out
the following operations (1) to (5) at each stage.
1. 9100 Use the front panel controls to set the 9100 Output to the UUT cal
point frequency and voltage, entering High Voltage State if the cal
point has been assigned to that State. The default High Voltage
State boundaries are shown in Fig. 4.19.1.
2. UUT Select the correct range for the cal point.
3. 9100 a. Set Output ON.
b. Note the UUT reading
4. UUT a. If a UUT calibration adjustment is provided, adjust the UUT
to equal the reading on the 9100 screen.
b. If no adjustment is provided on the UUT, record the UUT
reading at the calibration point
5. 9100 Set Output OFF.
4.19.6.3 Using the 9100 as an Adjustable Source
The following procedure assumes that the instrument is in Manual Mode. In the case of
difficulty, re-read sub-section 3.3.1. Familiarity with the methods of editing screen values
is also assumed (Section 3).
Calibration Setup
1. Connections Connect the 9100 as described, and ensure that both instruments are
powered ON and warmed up.
2. UUT Select DC Power function.
3. 9100 Ensure that the 9100 is in DC Power Function with Output OFF.
