4.5-12 Section 4: Using the Model 9100: DC Current Function
Final Width = 215mm
4.5.7 DC Current Routines for Calibrating UUTs
4.5.7.1 Interconnections
The general connection schemes for UUT calibration of DC Current Function are
illustrated in Figs. 4.5.2, 4.5.3 and 4.5.4.
For UUTs without safety banana sockets, use appropriate adaptors.
Fig. 4.5.2 Interconnections for DCI 'NORMAL OUTPUT' UUT Calibration
(Leads which are not shown are not connected)
10A mA COM V-
AA
AA
AA
AA
A
A
A
Cap
+
-
Thermo
Couple
+
-
I+mAI+ 20ALI-
sLsHH
WhiYellBlkBlkRedRed
Adaptor Parking Holes
Work Mat
UUT
