4.7-2 Section 4: Using the Model 9100: Resistance Function
Final Width = 215mm
4.7.2 Selection of Resistance Function
(Manual Mode selected)
4.7.2.1 'Ω' Key
Resistance is selected by pressing the
'Ω' key at the right of the 'CALIBRATION SYSTEM'
panel.
4.7.2.2 Default Settings
At power-on, the system defaults into DC Voltage function. Each time the Ω key is
pressed, the system defaults into Resistance function.
Whenever the Resistance menu screen is opened, except on recovery from a standby
period, it will appear with the following default settings:
x
∆
÷
U
U
T
i
ZERO
.
kΩ
Ω
Ω
Ω
CHANGE
CURRENT
4 WIRE
