4.9.6.3 Using the 9100 as an Adjustable Source
The following procedure assumes that the instrument is in Manual Mode. In the case of
difficulty, re-read sub-section 3.3.1. Familiarity with the methods of editing screen
values is also assumed (Section 3).
Calibration Setup
1. Connections Connect the 9100 to the UUT as shown in Fig. 4.9.2, and ensure that
both instruments are powered ON and warmed up.
2. UUT Select Frequency function.
3. 9100 Ensure that the 9100 is in Frequency Function with Output OFF. If
in any other function, press the '
Hz' key on the right of the front
panel, or the Hz screen key at the left of the bottom row.
Sequence of Operations
Refer to the table of UUT calibration points in the UUT Manufacturer's Calibration
Guide. Follow the correct sequence of calibration stages as directed by the guide, and
carry out the following operations (1) to (5) at each stage.
1. 9100 Use the front panel controls to set the 9100 Output to the UUT cal
point parameters:
Frequency
High signal level voltage.
Low signal level voltage.
2. UUT Select the correct range for the cal point.
3. 9100 a. Set Output ON.
b. Slew the required Output parameter reading until the UUT
reading or response is appropriate to the 9100 settings.
4. UUT Record the 9100 screen output values as detailed in the UUT
Manufacturer's Calibration Guide.
5. 9100 Set Output OFF.
