Section 4: Using the Model 9100: Auxiliary Functions 4.12-1
4.12 Auxiliary Functions
4.12.1
This sub-section is a guide to selecting one of the auxiliary functions. The following
topics are covered:
4.12.2 Selection of Auxiliary Functions.
4.12.2.1 'Aux' Key.
4.12.2.2 Default Settings.
4.12.3 Screen Keys.
4.12.3.1 Bottom Screen Keys.
4.12.3.2 No Right Side Screen Keys.
4.12.4 Result of Function Selection.
N.B. The functions of Option 250 or 600 (Oscilloscope Calibration Module) are
'Auxiliary' functions, and are added to the Auxiliary screen. For details of Option
250/600 functions, refer to the Model 9100 User's Handbook, Volume 3, Section
14, Sub-section 14.3.
