4.20-14 Section 4: Using the Model 9100: AC Power Function - Operation
Final Width = 215mm
4.20.6 Volt-Hertz Limits
4.20.6.1 Volt-Hertz Profile (Sinusoidal Waveshape)
The combination of voltage and frequency of the sinewave output signal is constrained
within the Volt.Hertz product envelope shown in Fig. 4.4.2. subject to further HF
limitations for power as stated in the specifications.
Any attempt to select a combination of voltage and frequency outside these constraints
will not be implemented. An audible warning will be given, accompanied by the screen
message: ‘Out of range’.
If the abortive attempt involves the use of Direct Editing, then a further message will be
placed into the active editing box.
The other four voltage waveshapes (see Section 4.4.3.4) have different limits:-
1kHz maximum up to 150V peak (nominal)
45Hz-55Hz above 150V peak (nominal)
