Section 5: Using the Model 9100 — Procedure Mode: Safety and General Notes 5.2-3
Final Width = 215mm
Front Panel Controls — Coarse Slewing Adjustments
Most initial slewing operations will require steps of adjustment larger than a single digit.
These coarser adjustments are available with the 'ENABLE CURSOR' key cancelled. Of
the front panel keys, only the spinwheel and the
and keys are enabled. The size of
their increments and decrements are calculated internally: one twentieth of the value
between the upper and lower limits of the specification tolerance at the subject test point.
