When changing between modes 2/4 (M2/M4) and modes 1/3(M1/M3), you will need to switch the gimbals around
so that the throttle gimbal is on the correct side.
8.3 Swapping Gimbals
1.Takethetransmitterapartusingascrewdriver,
removethe8screwsmarkedinred.
3.Reassemblythetransmitter.
4.Turnonthetransmitterandmakesureeverything
isworkingasexpectedviaMainmenu>GENER
MENU>MONITOR.
2.Swapthegimbalsandrotatethem180degrees,
thenlinethemupwiththescrewholesandsecure
thescrews.(Thereisnoneedtodisconnectthe
cables.).
