If you have purchased 2.4G antenna assembly inner-screw-inner-hole, the installation procedure is described
below.
8.6 Antenna Assembly Installation
2
3
4
SMA connector
(Outer-screw-inner-pin)
IPEX connector (1st generation)
1.Removethebackcoverofthetransmitterby
referringtotheprevioussteps,andthenremovethe
antennaholeplugsmalladhesivepiecewiththe
helpoftweezersandothertools.
3.Seethe󽗉gure.Inserttheplumwashersandspring
spacersinorder.Then,screwinthehexagonalnut,
andthentightentheantennapost.
4.Finally,closethebackcover.Pleasemakesure
thewireterminalsareingoodcontact.Note:You
needtoadjustthewireplacementwhenclosing
thecovertoavoidbeingpressedbythehousingor
otherparts.
2.Inserttheouter-screw-inner-pinendoftheIPEXto
SMAadaptercableintothecorrespondingposition
showninthe󽗉gure,andsnapthehexagonalnut
ontheend.SnaptheIPEXconnectorendofthe
adaptercableonthemotherboardantennaholder
andpress󽗉rmly.
Remove the antenna hole
plug small adhesive piece
with the help of tweezers
and other tools along the
direction as shown.
