FS-ST8
Digital Proportional Radio Control System
26
The following instructions explain how to change the non self-return to self-return.
8.2 Throttle Spring Installation
2
4
5
1.Takethetransmitterapartandremovethegimbal,
thenremovethetwoscrewswhichareshown
aboveandremovethebracket.
2.Loosentheassemblyscrewsshownabove󽗉rst,
thenremovetheplateassembly.Becarefulto
ensurenodamagetocables.
3
3.Insertthe2dowelsasshownabove.
4.Placethespringhookassemblyintopositionand
hookthespringontothehooklocatedinsidethe
transmitter.
5.Placetheplateassemblybackinitsoriginal
position,thensecureitwiththeoriginal4screws.
