If you have purchased the RF head adapter, 󽗉x it on the transmitter by following the steps below:
8.5 Stealth I/O RF Module Adapter Installation
1.PlacetheleftandrightRFmoduleadaptersas
showninthe󽗉gure.Remembertoalignthescrew
holes.
2.TightenthefourscrewstosecuretheRFmodule
adapters.
2
 Stealth I/O RF module interface
RX
GND
NC
S.port
PPM/TX
Note:ThetransmitterStealthI/ORFmoduleinterfaceisdesignedwithoutpowersupply,StealthI/ORFmodule
interfacepinsarede󽗉nedasshowninthe󽗉gurebelow.IfyouconnecttheRFmoduleexternallythroughtheRFmodule
adapter,youneedtosupplypowertotheRFmoduleseparately.
