Focus IMPULSE EVO PEDELEC - Page 12

US-12 Original User Guide | Impulse Evo pedelec Version 2
E-mountain bike
1
17
11
8
9
10
12
13
14
15
16
181920
2 3
22
23
24
21
25
26
1 Saddle
2 Saddle post
3 Crossbar
4 Stem
5 Handlebar and grip
6 Control unit
7 Display
8 Headset
9 Head tube
10 Suspension fork*
11 Battery including
docking station
12 Front brake*
13 Hub
14 Spoke
15 Rim
16 Tire
17 Motor
18 Pedal crank
19 Beltsprocket
or chain ring*
20 Belt or chain*
21 Back brake*
22 Chain stay
23 Gears
24 Cassette
25 Seat tube
26 Down tube
27 Saddle post clamp*
6
*depending on model
4 5
27
7
