Focus IMPULSE EVO PEDELEC - The Impulse Evo Pedelec and Its Components

Original User Guide | Impulse Evo pedelec Version 2 US-11
VI. The Impulse Evo pedelec and its components
*
3 6
7
10
12
14
17
19
18
20
21
15
24 2325
22
16
4
5
2
1
28
27
26
30
29
31
32
33
34
36
35
8
1 Rear light including
 redreector
2 Luggage rack
3 Saddle
4 Saddle post
5 Crossbar
6 Handlebar and grip
7 Bell
8 Stem
9 Control unit
10 Headset
11 Head tube
12 Front light including
 whitereector
13 Display
14 Mudguard
15 Suspension fork*
16 Battery including
docking station
17 Front brake*
18 Hub
19 Spoke
20 Rim
21 Tire
22 Motor
23 Pedal including two
 yellowreectors
24 Pedal crank
25 Beltsprocket
or chain ring*
26 Belt or chain*
27 Reectivestrips
28 Back brake*
29 Rear stand*
30 Chain stay
31 Gears
32 Cassette
33 Seat tube
34 Redrearreector
35 Down tube
36 Frame lock
37 Saddle post clamp*
38 Gear shifter
9
13
11
*depending on model
37
38
