US-98 Original User Guide | Impulse Evo pedelec Version 2
Screwxing Thread Tightening torque
Ahead stem steerer
tube
M5 / M6 / M7 M5: 5 / M6: 10 / M7: 14 M5: 3.7 / M6: 7.4 /
M7: 10.3
Bar end, external
clamp
M5 / M6 M5: 5 / M6: 10 M5: 3.7 / M6: 7.4
Saddle clamp bottom M5 / M6 / M8 M5: 5 / M6: 10 / M8: 20 M5: 3.7 / M6: 7.4 /
M8: 14.8
Saddle clamp top M5 / M6 / M7
/ M8
M5: 5.5 / M6: 5.5 /
M7: 14 / M8: 20
M5: 4.1 / M6: 4.1 /
M7: 10.3 / M8: 14.8
Rim brake shoe M6 10 7.4
Sliding drop-outs M10 16 11.8
Disc brake calliper,
Shimano IS and PM
M6 6 – 8 4.4 - 5.9
Disc brake calliper,
Avid IS and PM
M6 8 – 10 5.9 - 7.4
Disc brake calliper,
Magura IS and PM
M6 6 4.4
Gear lever clamp M5 5 3.7
Brake lever clamp M5 Ref. manufacturer's spec. -
Cassettexingring N/A 30 – 40 22.1 - 29.5
Screw-on handlebar
plugs
M4 / M5 M4: 3 / M5: 5 M4: 2.2 / M5: 3.7
Motor housing M5 5.9 -
Motor bolts M8 25 -
Luggage rack M5 / M6 M5: 5 – 6 / M6: 8 – 10 -
WARNING
Correct tightening torque of threaded fasteners is very important to
your safety. Always tighten fasteners to the correct torque. In case
ofaconictbetweentheinstructionsinthismanualandinformation
provided by a component manufacturer, consult with your dealer or
themanufacturer’scustomerservicerepresentativeforclarication.
Bolts that are too tight can stretch and deform. Bolts that are too
loose can move and fatigue. Either mistake can lead to a sudden
failure of the bolt.
Always use a correctly calibrated torque wrench to tighten critical
fasteners on your bike. Carefully follow the torque wrench
manufacturer’s instructions on the correct way to set and use
the torque wrench for accurate results.
If no values are shown on the component or component manuals, use the
torque settings from the following table.
Screwxing Thread Tightening torque
Nm ft·lb
Pedal crank screw M6 10 7.4
Pedal crank arm M6 12 – 14 8.9 - 10.3
Pedal 9/16 40 29.5
Front axle nut General 25 – 30 18.4 - 22.1
Rear axle nut
General
35 – 40 25.8 - 29.5
Stem cone M8 23 17
Ahead stem angle
adjustment
M6 8 – 10 5.9 - 7.4
Ahead stem handlebar
clamp
M5 / M6 / M7 M5: 5 / M6: 10 / M7: 14 M5: 3.7 / M6: 7.4 /
M7: 10.3
