36 25CI400A/W • 25HI400A • 50CI400A/W • 50HI400A

Dispense chute and splash panel areas (lever models) — Serial Numbers below D61292

Reference Description Part #

1 Fastener, dispense chute bracket 502057

2 Tube, water station 00187682

3 Bracket, lever 00185116

4 Switch, dispense, ice, lever actuated (includes 502418) 502409

5 Lever, dispense 00182808

6 Chute, ice, bracket and fasteners (with Agion) 00981241

6 Chute and funnel (clear), ice 00192948

7 Chute, water, bracket and fasteners (with Agion) 00981407

7 Chute (clear), water 00184390

8 Elbow, 3/8" 502925

9 Bracket, water solenoid 00182832

10 Fitting, inlet, 1/8" MPT x 1/4" comp 502246

11 Fitting, outlet, 1/8" MPT x 3/8" comp 502262

12 Solenoid valve, water, 120 V, 60Hz 502243

13 Boot, dispense switch button (mounts on 502409 switch) 502418

Not shown Tubing, water station, thermoplastic, 1/4" OD (sold by the foot) 502079

14 Splash panel, lever dispense 00192922

14 Splash panel, lever dispense, ice only 00969220
