Follett 25CI400A - Ice Machine Removal and Evaporator Service

16 25CI400A/W • 25HI400A • 50CI400A/W • 50HI400A
Fig. 18 – All models
18.1
18.2
3. Lower drain pan protector (Fig. 18.1). Remove and
discard shipping screw (Fig. 18.2).
Fig. 19 – All models
19.1
19.2
19.4
19.3
4. Close main water shut off valve (Fig. 19.1).
5. Disconnect water line to  oat valve (Fig. 19.2).
6. Disconnect water line to solenoid (Fig. 19.3).
7. Remove screws securing bottom of ice machine
electrical box (Fig. 19.4).
Ice machine removal
To reduce risk of shock disconnect power before
servicing.
!
WARNING
Fig. 16– All models
1. Remove front cover (Fig. 16).
Fig. 17 – All models
2. Remove splash panel (Fig. 17).
