25CI400A/W • 25HI400A • 50CI400A/W • 50HI400A 5
Electrical
115 V, 60 Hz, 1 phase, 14.0A. Connect to dedicated 20A circuit, fuse or breaker.
Note: It is preferred that circuit be protected by a GFCI.
Furnished with 7 ft (2 m) power cord with a 90° NEMA hospital grade 5-20 plug.
Ambient
Maximum Minimum
Air temp 100 F/38 C (Best performance below 80 F/27 C) 50 F/10 C
Water temp 90 F/32 C (Best performance below 70 F/21 C) 40 F/4 C
Water pressure 70 psi (483 kpa) 10 psi (69 kpa)
Plumbing
Connections – 25/50CI400A/W Rough-ins – 25/50HI400A/
Dispenser drain All – 3/4" FNPT Air-cooled – 3/4" FNPT
Water inlet All – 3/8" FNPT All – 1/2" FNPT
Condenser inlet Water-cooled – 3/8" FNPT N/A
Condenser outlet Water-cooled – 3/8" FNPT N/A
Note: Water shut-off recommended within 10' (3 m) of dispenser. Drain to be hard-piped and
insulated. Maintain at least 1/4" per foot (20 mm per 1 m run) of slope on horizontal runs.
CAUTION
• Do not block left side air intake or right side air exhaust
Ventilation and service clearances
Air-cooled Water-cooled
Required for ventilation 3" (77 mm) each side N/A
Suggested for service 12" (30.5 cm) top,
6"(15.3 cm) left side
12" (30.5 cm) top
Uncrated weight
25/50CI400A/W (countertop) 215 lbs (98 kg)
25/50HI400A (wall mount) 230 lbs (105 kg)
