Follett 25CI400A - Dispense Chute and Splash Panel Areas (Sensorsafe Models) - Serial Numbers below D61292

25CI400A/W • 25HI400A • 50CI400A/W • 50HI400A 39
Dispense chute and splash panel areas (SensorSAFE models) — Serial Numbers below
D61292
14
6
15
5
10
1
2
12
4
3
9
7
1
13
11
8
Reference Description Part #
1 Fastener, dispense chute bracket 502057
2 Tube, water station 00187682
3 Sensor, ice dispense 00195982
4 Sensor, water dispense 00195982
5 Lens, sensors 00196006
6 Clean switch, SensorSAFE (includes 501841) 502359
7 Chute, ice, bracket and fasteners (with Agion) 00981241
7 Chute and funnel (clear), ice 00192948
8 Chute, water, bracket and fasteners (with Agion) 00981407
8 Chute (clear), water 00184390
9 Elbow, 3/8" 502925
10 Bracket, water solenoid 00182832
11 Fitting, inlet, 1/8" MPT x 1/4" comp 502246
12 Fitting, outlet, 1/8" MPT x 3/8" comp 502262
13 Solenoid valve, water, 120 V, 60Hz 502243
14 Boot, clean switch button (mounts on 502359 switch) 501841
Not shown Tubing, water station, thermoplastic, 1/4" OD (sold by the foot) 502079
16 Splash panel, SensorSAFE dispense with drain pan (includes 00196006) 00192930
16 Splash panel, SensorSAFE dispense with drain pan, ice only (includes 00196006) 00969238
16 Splash panel, SensorSAFE dispense, no drain pan (includes 00196006) 00902072
16 Splash panel, SensorSAFE dispense, no drain pan, ice only (includes 00196006) 00969246
