Fox Thermal FT3 - Analog 4-20 mA Outputs

If the wrong password is entered, the message “Wrong Password” will display and then return to the
programming entry screen.
SET PARAMETERS Menu (Main Menu)
If the password is accepted, the SET PARAMETERS menu will be shown:
F1 F2 F3 F4
This is the screen for the programming mode. Press EXIT (F4) repeatedly until “Normal Mode” is
seen briey to exit the programming mode.
Analog 4-20mA Outputs
The following menu allows the scaling of the analog 4-20mA output. From the SET PARAMETERS
menu, press I/O (F1) to move to the 4-20mA output selection.
F1 F2 F3 F4
In this screen press 420 (F3) (screen appearance may vary according to options).
F1 F2 F3 F4
Select CH1 (F1) to program channel 1.
F1 F2 F3 F4
Enter the value for the 20mA and press OK (F4) key to accept the setting.
NOTE! When the ow rate exceeds the programmed value for the 20mA set point, the analog
output will stay at 20mA and an alarm code will be generated.
SET PARAMETERS
I/O FLO DSP EXIT
SET I/O
COM I/O 420 EXIT
SET 4-20 mA
CH1 CH2 EXIT
20 mA = 3500 SCFM
CHG OK
Operation | 54
Model FT3
Operation
