To exit the programming mode, press (F4) repeatedly until Normal Mode is seen.
Select CH2 (F2) to program channel 2. Channel 2 is programmable for ow (CH2=Flow) or
temperature (CH2=Temp).
F1 F2 F3 F4
Press NXT (F1) to select Flow or Temperature and then press OK (F4).
F1 F2 F3 F4
Enter the value for the 20mA and press OK (F4) key to accept the setting.
Then the following screen will display:
F1 F2 F3 F4
Enter the value for the 4mA and press OK (F4).
Press (F4) repeatedly until “Normal Mode” is seen briey to exit the programming mode.
Pulse/Alarm Output
From the SET PARAMETERS menu, press I/O (F1), then I/O (F2).
F1 F2 F3 F4
Press OUT (F2) to select output. The following screen will show:
F1 F2 F3 F4
Press NEXT (F1) to cycle through output options until you have the selection for "OUT=Frequency"
and press OK (F4).
CH2 = Temp
NXT OK
20 mA = 300 º F
CHG OK
4 mA = 10 º F
CHG OK
SET I/O
INP OUT EXIT
OUT = Frequency
NXT OK
Operation | 56
Model FT3
Operation
