Pressing F2 and F3 simultaneously:
F1 F2 F3 F4
Password needs to be entered if active (default: 1234):
F1 F2 F3 F4
After entering a valid password, a brief conrmation message will be displayed for 1 second:
F1 F2 F3 F4
Programming Contact Input for Curve Switching
Enter the menu using steps outlined in "Contact Input Settings" section (p. 59) and select "Switch
CRV". Please note that the ow meter needs to be programmed for 2 gas curves at the Fox factory
before you can select this function. Flow meters are shipped with pre-programmed user requested
settings.
F1 F2 F3 F4
Selections are: "Not used"
"Tot Reset"
"Switch Crv"
NOTE! Helpful hint: From normal display mode, press F4 to view the current gas curve
selection.
Operation of the 2 Gas Curves
To avoid confusion, only one of two techniques is enabled. If the contact input is assigned to switch
gas curves, then the ability to switch using the F2 and F3 function keys on the front panel is disabled.
SWITCH TO CRV 1?
NO YES
PASSWORD:_
UP DN NXT OK
SWITCH TO CRV 1
INP=SWITCH CRV
NXT OK
