Display Setup
There are four display screens that you can cycle through in normal operating mode (see Fig. 4.2 on
p. 51). Two of the four display screens are xed and cannot be changed (Display 3 and Display 4).
The other two screens are programmable to show the information that you prefer.
Display #1 Display #2
F1 F2 F3 F4 F1 F2 F3 F4
Selections are:
DSP1L1 = Display 1, Line 1
DSP1L2 = Display 1, Line 2
DSP2L1 = Display 2, Line 1
DSP2L2 = Display 2, Line 2
To Program Display Screens #1 and 2
From the SET PARAMETERS menu press DSP (F3) to select the DISPLAY menu:
F1 F2 F3 F4
Press DSP (F1) key. The display will show:
F1 F2 F3 F4
These are the selections for the Display 1, Line 1.
Selections are:
Flo rate = Flow rate
Total = Total mass or volume
Elps = Elapsed time
Temp = Temperature
Alarm = Error codes
When the selection is correct, press OK (F4) to accept. The display will then go through the same
process for all 4 lines of the 2 programmable displays (DSP1L1, DSP1L2, DSP2L1 and DSP2L2).
After the last line of Display 2 is accepted, the display will show the following menu:
F1 F2 F3 F4
DSP1L1
DSP1L2
DSP2L1
DSP2L2
DISPLAY/PASSWORD
DSP IR PSW EXIT
DSP1L1 = Flo rate
NXT OK
ALTERNATE = O
NXT OK
