F1 F2 F3 F4
Press YES (F1) to start the simulation mode, otherwise press NO (F4). Upon pressing either key, the
program will return to the FLOW PARAMETER 1 screen.
NOTE! Simulation Mode will be cleared if the power is cycled.
Calibration Parameters
This menu allows changing the factory calibrated setting of the ow meter and is accessible with a
Level 2 password. Calibration parameter values are set for temperature and pressure at 0 degree C
and 760 mmHg. These settings should normally never be changed except by Fox Thermal personnel
at the factory.
This calibration menu is entered from the SET PARAMETERS menu by pressing FLO, PRM, and CAL.
F1 F2 F3 F4
Press CAL (F1) then the display will show:
F1 F2 F3 F4
Press TB1 (F1) then the display will show:
F1 F2 F3 F4
Press NXT (F3) then the display will show:
F1 F2 F3 F4
Use the CHG (F1) key to change the entry, PRV (F2) to move to the previous entry, NXT (F3) to move
to the next entry and EXIT (F4) to return.
ENABLE SIM?
YES NO
FLOW PARAMETER 2
CAL SPC PRM EXIT
CAL TABLE
TB1 - - - - - - EXIT
Volt1 = 0.92367
CHG PRV NXT EXIT
Flo1 = 0
CHG PRV NXT EXIT
