Table 5.1: FT3 Modbus Holding (cont'd)
Communications | 92
Model FT3
Communications
Modbus
Register
Data Type Description Units
40020 32-bit oat LSW Flow User selected
40021 32-bit oat MSW
40022 32-bit oat LSW Total User selected
40023 32-bit oat MSW
40024 32-bit oat LSW Total 2 (2 gas curves only) User selected
40025 32-bit oat MSW
40026 32-bit oat LSW Temperature User selected
40027 32-bit oat MSW
40028 32-bit oat LSW Elapsed Time Hours
40029 32-bit oat MSW
40030 32-bit oat LSW Flow Velocity Meters/hour
40031 32-bit oat MSW
40032 32-bit oat LSW CAL-V Di CAL-V Di
40033 32-bit oat MSW
40034 32-bit oat LSW CAL-V Set CAL-V Set
40035 32-bit oat MSW
40036 16-bit int Reserved
40037 32-bit int LSW Total 24 hrs, Last total record User selected
40038 32-bit int MSW
40039 16-bit int Total 24 hrs, Current Day (0-6) Day
40040 16-bit int Total 24 hrs, Current Hour (0-23) Hour
40041 32-bit int LSW Total 24 hrs, Record day 1 User selected
40042 32-bit int MSW
40043 32-bit int LSW Total 24 hrs, Record day 2 User selected
40044 32-bit int MSW
40045 32-bit int LSW Total 24 hrs, Record day 3 User selected
40046 32-bit int MSW
40047 32-bit int LSW Total 24 hrs, Record day 4 User selected
40048 32-bit int MSW
40049 32-bit int LSW Total 24 hrs, Record day 5 User selected
40050 32-bit int MSW
40051 32-bit int LSW Total 24 hrs, Record day 6 User selected
40052 32-bit int MSW
40053 32-bit int LSW Total 24 hrs, Record day 7 User selected
40054 32-bit int MSW
40055 32-bit int LSW Total 24 hrs, Last Total User selected
40056 32-bit int MSW
40057 32-bit oat LSW Zero Check Mean Zero Check Mean value
40058 32-bit oat MSW
40059 32-bit oat LSW Zero Check Stdev Zero Check Standard Deviation
40060 32-bit oat MSW
