The FOXTEL iQ
Optional audio connections
This diagram shows the optional audio connections you can make
to obtain improved quality sound.
You can connect to stereo audio equipment as shown, or
alternatively, if your TV and/or video recorder has the correct input
connectors, you can connect to these as required.
CABLE INPUTCABLE INPUT
R
AUDIO
OUT
DIGITAL AUDIO OUT
(FIXED AUDIO)
TELEPHONE
LINE
USBETHERNET
COAXIAL
OPTICAL
L
VCR SCART (FIXED AUDIO)
TV SCART
12V DC
3.5A MAX.
-
+
Analogue
stereo audio
phono leads
Coaxial (75Ω)
digital audio lead
Optical digital
audio lead
