2.4 Safety Devices
1
Key for automatic mode
In case of overheating of the boiler:
 Press and hold the key for 5 seconds
Automatic mode is switched off
Control follows the boiler shutdown procedure
The pumps continue to run!
2
Safety temperature limiter
(STL)
Switches off the blower fan at the maximum boiler temperature of
220 °F (105 °C). The pumps continue to run!
 Once the temperature falls to below approx. 203 °F (95 °C),
the STL can be reset mechanically.
2.4.1 Devices for Preventing the Boiler from overheating
The P4 Pellet boiler comes with safety systems to prevent the following:
 Pressure in the boiler exceeding 30 psi (2 bar) (over pressure)
 Boiler water temperature exceeding 220ºF (105º C)
