Froling P4 - Check the Grate and Combustion Chamber

Page 42
B0430207 I
5
 Take the ash container to the
emptying point and empty it
 To remove the cover the clamp
must be unlocked and opened
Check the grate and combustion chamber
 Only clean the grate and combustion chamber when the boiler
has cooled down
 Press and hold the key for 5 seconds
 Boiler follows shutdown procedure and changes to the
status “Burner off”
 The ID fan turns at a controlled speed and the
combustion grate stays in open position.
for P4 Pellet 8/15/20/25:
 Open the insulating door, open the right ash door and pull out
the ash drawer
For P4 Pellet 32/38, 48/60, and 80/100:
 Open the insulating door, take out the right ash container and
open the ash door
 Check the combustion grate and combustion chamber for dirt
 If there is a lot of dirt, clean the combustion chamber
Page 43, Clean the flue gas collection chamber and the heat
exchanger
