Froling P4 User Manual

Fröling Heizkessel- und Behälterbau Ges.m.b.H, Industriestrasse 12, A-4710 Grieskirchen Page 9
Tel +43 (0) 7248 606-0 Fax +43 (0) 7248 606-600 info@froeling.com www.froeling.com B0430207
1
Pos
Component
1
P4 Pellet with integrated Pellets cyclone container
2
Lambdatronic P 3100 control system
2.1
Navigation keys to move around in the menus and to change the parameter values
2.2
Status LED (operating status): - slow green flashing light: boiler activated
- fast green flashing light: boiler deactivated
- flashing red light: malfunction
2.3
Large graphical display to show operating statuses and parameters
2.4
Function keys for calling up individual boiler functions or modes directly
3
Ash drawer - heat exchanger
4
Ash drawer - Combustion chamber
5
Ash drawer
6
Ash container - heat exchanger
7
Ash container - combustion chamber
8
Ash screw and stirrer of the automatic heat exchanger cleaning
9
Ash screw and guide plates of the combustion chamber cleaning
10
Lever of the ash box lock
11
Service interface of the control
12
Safety temperature limiter - STL
1.1 Boiler Fabrication and Testing
Your boiler was manufactured by Fröling, a world leader in hot water
(hydronic) heating for over 40 years. The P4 Pellet boiler conforms to
traditional high standards for quality and reliability. It offers modern
pellet boiler technology with high operating efficiencies at over 90%. If
treated properly and operated according to the guidelines in this manual
it will provide years of safe, dependable, and economical heating.
P4 Pellet boilers are designed and built in accordance with European
Standard EN 303-5. Safety and performance testing and listing for North
American markets have been performed by OMNI Test Laboratories,
Inc., Portland, Oregon. The boiler is tested and listed to applicable UL,
CAN and other standards. The boiler is not ASME stamped. The installer
should follow local or state installation requirements.
The P4 Pellet boiler is a pellet boiler designed and constructed for highly
efficient combustion of wood pellets.
Do not burn other fuels in the P4 Pellet boiler. The P4 Pellet boiler is not
a self contained weather-tight boiler. It should be installed within the
heated building. P4 Pellet boilers should be installed with a thermal
storage system to prevent short-cycling of the boiler during periods
when the building is not calling for heat.
1.2 Models and Applications
Five P4 Pellet boiler models are available (8/15, 20/25, 30/38, 48/60),
and 80/100 covering an output range between 35,800Btu/hr and
330,000Btu/hr. Models 8/15, and 20/25 is available with a pneumatic
hopper or 280 lb (240 liter) day bin. Specification data for each P4 Pellet
boiler is provided in the Installation Manual. The boilers can be utilized
as a single heat source, or in parallel with another boiler.

Froling P4 Specifications

General

Model	P4
Category	Boiler
Fuel Type	Wood Pellets
Automatic Ignition	Yes
Automatic Cleaning	Yes
Touchscreen Control	Yes
Remote Monitoring	Yes
Weight	Varies depending on model
Dimensions (H x W x D)	Varies depending on model
