Froling P4 - Emptying the Ash Container (for P4 Pellet 32;38 and 48;60)

Fröling Heizkessel- und Behälterbau Ges.m.b.H, Industriestrasse 12, A-4710 Grieskirchen Page 41
Tel +43 (0) 7248 606-0 Fax +43 (0) 7248 606-600 info@froeling.com www.froeling.com B0430207
5
 Take the ash
drawers out a bit
 This pushes
the ash lying
in front of the
drawer into
the ash bowl
 Thread in the
transport cover
as illustrated and
pull out the ash
drawer, until the
cover settles into
position
 Take the ash
drawer to the
emptying point
and empty it
 To remove the
transport cover
the locking lever
must be pushed
up
Emptying the ash container (for P4 Pellet 32/38, 48/60, 80/100)
 Open insulation door
 Push the locking lever upwards
 Pull out the ash container
 Put the cover cap supplied on the
flange of the ash container
