Remove the insulating cover and cleaning cover
Page 43, Clean the flue gas collection chamber and the heat
exchanger
Push the lock bolt upwards and remove
Remove the WOS mount along with the springs
Clean the heat exchanger pipes with cleaning brush
Cleaning the induced draught ventilator
Detach the induced draught ventilator
on the back of the boiler
Check for dirt and damage
Clean the blower wheel with a soft
brush or paint brush
Do not move the balancing weights
on the blower wheel!
Clean the smoke flue pipe
Clean the connecting pipe between the boiler and the chimney
regularly with a chimney sweeping brush
Depending on the layout of the flue pipes and the chimney
draught cleaning yearly may not be enough!
Soot and Flyash: Formation and Need for Removal-The products of
combustion will contain small particles of flyash. The flyash will
collect in the exhaust venting system and restrict the flow of the flue
gases. Incomplete combustion, such as occurs during start-up,
shutdown, or incorrect operation of the heater will lead to some soot
formation which will collect in the exhaust venting system. The
exhaust venting system should be inspected at least once every year
to determine if cleaning is necessary.
