Fronius IG Plus 5.0-1 User Manual

109
The identification number of the
IG Brain unit is shown
6. Press the ‘Down’ key to display
the hardware version of the IG
Brain unit
The hardware version of the IG
Brain unit is shown
7. Press the ‘Esc’ key
‘MAINCTRL’ is shown
8. Press the ‘Down’ key to display
the power stage sets
The component ID of the IG
Brain unit is shown
5. Press the ‘Down’ key to display
the identification number of the
IG Brain unit
The version number of the IG
Brain unit is shown
4. Press the ‘Down’ key to display
the component ID.
‘MAINCTRL’ is shown
3. Press ‘Enter’ to display the
version number of the IG Brain
unit
Displaying
menu item
‘VERSI
ON’
(continued)

Fronius IG Plus 5.0-1 Specifications

General

Nominal AC Power	5000 W
AC Nominal Voltage	230 V
Frequency	50 / 60 Hz
Max Apparent AC Power	5000 VA
Max Output Current	21.7 A
THD	< 3 %
Inverter Design	Transformerless
AC Connection	Screw terminals
