Consumables
Liner Installation Procedure
1 - Whips should be laid out straight prior to installation
2 - Be sure liner is fully inserted in the whip and remove all of the free play.
3 - Cut liner flush with the diffuser and remove any burrs present after cutting.
4 - Contact tip should apply pressure against the inner liner as it is threaded into the diffuser.
1.
2. 3.
Graphite/Teflon Liner Tools
-
--
- 67
67 67
67 -
--
-
