3. Machine Set Up QD002-07
90 NXT Setup Manual
Pneumatic Connections
<For the Independent 4M Base (serial No. up to 294)>
T1 tubes (2)
Independent 4M base
Dependent
2M base
Reuse the plugs.
Attach the used plugs.
Remove the plugs (2), and
then connect the T1 tubes.
NXTSET028Ea
