System expansions
Opening the casing
Casing,M achine
Note that various of the components on the motherboard can be still very hot if the
machine had been in use a short while previously.
These components can be identified by the following symbol.
► Switch the machine off. Make sure the machine is off, and not in power-saving mode!
Follow the safety instructions on the modules in chapter "Important notes",
Page 3 as well as in the manual on "Safety".
Unplug the m ains plug from the mains socket.
Don’t plug the mains plug back into the mains socket until you have
closed the casing up again.
► Disconnect any cables that make access difficult.
1
1
1
1
1
AMILO Desktop L/P AMILO Desktop S
► Using a cross-head screwdriver (1), unscrew the casing screws.
AMILO Desktop Operating Manual, edition 3 33
