Getting started
Settingupthedevice
Videoworks tationErgonomicDevice,
When installing your device, please read the reco mmendations and
safety notes in th e "Safety" man ual.
Do not place the machine in any position other th an the one intended (upright on its feet).
We recommend that you place your device on a su rface with good anti-slip qualities.
In view of the multitude of different finishes and varnishes use d on furniture, it is
possible that the rubber feet will mark the surface they stan d on.
Do not stack several devices on top of each other.
Do not start the machine in any position other than upright on its feet.
Depending on the location of your machine, it may emit annoying vibration or noises.
To avoid this, allow a minimum clearance of 3 mm from other equipment or objects
at the sides of the c asing where there are no ventilation grilles.
Make sure that the device is adequately ventilated. In order to avoid overhe ating,
do not cover the ventilation area of the monitor o r the device.
Do n ot expose the device to extreme ambient conditions (see "
Technical data", Page
52, "Ambient conditions"). Protect the dev ice ag ainst dust, humidity and heat.
Connections and Controls
This chap ter describes the in
dividual hardware components of your machine. It gives
you an overview of the display
s and connections of the machine . Familiarise yourself
with these elements before yo
u start to use the machine.
Connections
Description Figure Symbol
PC power supply
Mains connection
Sound (external so und source s, e.g.
active loudspeaker, microphone)
• Sound on board
When an additional sound card is
installed, there is no sound function
on the motherboard, and “Sound
onboard“ is not available.
3.5 mm jack sockets
Line In
Line Out
Mic
AMILO Desktop Operating Manual, edition 3 7
