System expansio ns
Reinstallin g a slot cover
For c ooling, protection against fire, and in order to comply with EMC (electromagnetic
compatibility) regulations, you must re fit the slot cover.
2
1
► Push the slot cover into the slot (1).
► Fasten the screw (2) when present.
2
1
► Place the cover angle at its installation slot over the module slots (1)
andsecureitwiththescrew(2).
► Close the casing (see "
Closing the casing", Page 35).
If you have installed or removed a board, please check the relevant PCI
slot settings in the BIOS Setup. If necessary, change the settings. Furth er
information is provided in the PCI board documentation.
44 AMILO Desktop Operating Manual, edition 3
